Coltene Spec 3 LED Curing Light

• 3 Distinct Power Modes
• Ergonomic lightweight design
• High intensity output for rapid polymerization
• Intuitive and simple controls for ease of use

Wavelength output : 430 nm – 490 nm

Power Supply :

• Input: 100V – 240V AC / 50 ~ 60 Hz
• Output: 6V DC, 2.5A

Dimensions :

• Component - S.P.E.C. 3® Curing Light
• Handpiece - 174.5 × 24.8 (mm)
• Power Adapter - 47 × 87 × 32 (mm),
• Charger Base - 136 × 86 × 60 (mm),
• AC Power Cord - 1.3m
• Intensity of irradiation Standard Mode: 1,600 mw / cm2 ± 10%
• Intensity of irradiation Mode 3K and Ortho: 3,000-3,500 mw / cm2

• 1 x LED curing light
• 1 x Charger Base
• 1 x Power Adapter
• 1 x Instruction Guide
• 1 x Eye Shield
• 1 x Composite curing test block

Installation procedure :

• Gently insert the light guide into the opening on the handpiece. When light guide is fully inserted, approximately 1mm of the metal ring will be exposed.
• Place the barrier sleeve over the curing light. Put the eye shield over the end of the light guide drawing the barrier sleeve taut.
• Plug the AC power cord into the receptacle in the power adapter.
• Connect the S.P.E.C. 3® LED Charger Base to the power adapter. Insert the plug on the power adapter completely into the wall electrical outlet.
• Keep the handpiece on the charger base when not in use.

Powering ON and OFF :

• The battery charge level display: Three green lights indicate a fully charged LED curing light. One or two green lights indicate the curing light is not fully charged. The unit beeps one time after displaying the battery charge level indicating the LED is ready to use.
• Power ON: Press the Shot switch or the Mode switch to activate the S.P.E.C 3® Curing Light.
• Power OFF: S.P.E.C. 3® LED Curing Light turns off automatically after 5 minutes if no operation is detected (Sleep mode).
• If the curing light is in ”Sleep” mode, pressing any switch will “awaken” the light to the curing mode last used.

Basic Controls :

• Mode switch: Press the Mode switch quickly to select various time
  settings. Press and hold the Mode Switch for 3 seconds to switch between curing modes. Two beeps are emitted.
• Shot switch: Press the Shot switch to start the selected curing program. Press the Shot switch during operation to stop the program in progress.

Mode selection :

• 3K Mode / Ortho Mode: When selected, the LED display turns to ORANGE color. The output will be 3000 mW/cm².
• Standard Mode: When selected, the LED display turns to GREEN color. The output will be 1600 mW/cm². Press and hold the Mode switch for 3 seconds to change curing mode (GREEN and ORANGE light changes alternately).

• Country Of Origin: Korea
• Manufacturer: Coltene Whaledent

• Manufacturer/Importer warranty of 24 months as applicable for this product.
• Service and Warranty are handled by the manufacturer/importer directly for this product
• Oralkart will not be liable to replace the Products and the liability to replace any such Product is that of the Manufacturer/Importer
• Oralkart and the Buyer acknowledge that the Products purchased/usedare a subject matter of original Manufacturer/Importer’s warranties only
• Any or all claims in relation to returns and replacement shall be made to the concerned Manufacturer/Importer only and Oralkart may assist the customer in registering a request to get the Product replaced or serviced.
• The Buyer acknowledges that the Products once sold will not be exchanged or taken back unless the seal of the package or the Product is intact or not altered in any manner or is not tampered as the case may be.

Question: If the Shot or Mode button doesn’t light up?
Answer: Removing the battery pack and reinserting it will reset the device to its original factory settings. On the base of the handpiece, remove the two miniature screws with the enclosed phillips head screw driver provided. Slide the battery pack out of the handpiece and reinsert it, replacing the two miniature screws. Place the handpiece on the charger base to recharge until the red light changes to the green illuminated light indicating a fully charged curing light. This will resolve a low-power problem.

Question: If the Shot or Mode button lights up but doesn’t work properly?
Answer: The curing light may be discharged and needs recharging.
Place the handpiece on the charger base to recharge until the red light changes to the green illuminated light indicating a fully charged curing light. If the curing light does not activate, the unit requires service. Please contact your supplier or authorized service center.

Question: Is this item autoclavable?
Answer: The handpiece is not autoclavable. Do not sterilize the handpiece by immersion or heat sterilization such as dry heat, steam under pressure, or unsaturated chemical vapor (fiber-optic light guide and light shield can be autoclaved).
